R290 Direct Cooling Double Foaming Door Medical Low Temperature Freezer -40 Degree

1
MOQ
$ 2142-2346 per set
Price
R290 Direct Cooling Double Foaming Door Medical Low Temperature Freezer -40 Degree
Features Gallery Product Description Request A Quote
Features
Specifications
Cooling Method: Direct Cooling
Refrigerant: R290
Defrost: Manual
Capacity(L/cu.ft): 358/9.81
NT./GT.(kg): 138/178
Power(W): 310W
Condenser: Wire Tube
Package Size(W*D*H)(mm): 780×920×1990
High Light:

Direct Cooling Low Temperature Freezer

,

R290 Refrigerant Laboratory Deep Freezer

,

Minus 40 Degrees Laboratory Deep Freezer

Basic Infomation
Place of Origin: ANHUI CHINA
Brand Name: PROMED
Certification: ISO9001;13485;14001;CE;FDA LIST
Model Number: MDF-40V358
Payment & Shipping Terms
Packaging Details: Carton packing with strong belt Package size(W*D*H) 780×920×1990mm / 20GP/40GP/40HQ - 18/39/39 pieces
Delivery Time: 7-25 days after reveing 50% deposit
Payment Terms: T/T, Western Union, L/C, MoneyGram, D/A, D/P
Supply Ability: 700 Pieces per month
Product Description

Double Door And Dual Control Systerm Medical Low Temperature Freezer -40 Degree

LED Display Smart Medical Refrigerator Pharmacy Refrigerator Vaccine Refrigerator

Product Description





Main Features

  • USB data logging and temperature recorder (optional).
  • Build-in lock with safety and beauty
  • Lockable caster design for customer to move as needed
  • Microprocessor control, adjustable temperature range: -20CºC to -40ºC
  • LED digital display and increment at 0.1ºC
  • Independent inner door to avoid more cooling leaking out, and provide more stable inside temperature performance
  • High density CFC-Free urethane foam insulation.

Safety

  • Multiple malfunction alarms :high and low temperature , sensor error, power off, temperature controller malfunction, door ajar alarms.
  • Alarm indications: audible buzzing alarm and visual flashing light alarm
  • Corrosion proof cabinet interior design
  • Power failure protect: the device would be attack by the high current when all devices restart simultaneously, the start-delay function would protect device from the damage
  • Optimized refrigeration system designed to maximize cooling effect and temperature uniformity
  • LED digital display for clear observation,
  • Wide voltage tolerance design with applicable voltage range of 187-242V/AC



Product Description



-40ºC Deep freezer



-40ºC Medical Deep Freezer is specially designed and manufactured for long term storage of various biological products, including viruses, germs, erythrocytes, leucocyte and cutis. Applications can be found in blood banks, hospitals, edipemic prevention service, and research institutes, laboratories in electronic and chemical plants, biological engineering institutes and marine fishery companies.
Double Door Medical Low Temperature Freezer -40 Degree
Double Door Medical Low Temperature Freezer -40 Degree

KEY FEATURES
  • Chemically stable, CFC -free, commercially available and environmentally safe refrigerant.
  • Microprocessor control, adjustable temperature range: -20°C to -40°C
  • LED digital display and increment at 0.1 °C.
  • Permanently lubricated cooling fan for safety and longevity.
  • Wide voltage band for 187V-242V.



SAFETY GUARANTEE
  • Multiple malfunction alarms to detect high and low temperature , sensor error, power failure, temperature controller malfunction
  • Two types of alarm indications: audible buzzing and visual flashing light.
Double Door Medical Low Temperature Freezer -40 Degree
Double Door Medical Low Temperature Freezer -40 Degree

BOX
  • The box is made of high quality cold rolled steel plate, and the surface is treated with advance anti-corrosion phosphatic spraying process with elegant orange powder coating. High-class 304 SUS inner box, durable and reliable.
TEMPERATURE CONTROL MODE
  • With the famous brand computer temperature control system to keep the inner temperature accurate and stable. Temperature adjusted from -25°C~-60°C.
  • High light digital display
  • High/low temperature alarm, the alarm temperature can be set as needed
  • Platinum esiance temperature sensor, sensing temperature accurately
Double Door Medical Low Temperature Freezer -40 Degree

Double Door Medical Low Temperature Freezer -40 Degree

REFRIGERATION SYSTEM
  • Imported brand compressor work with CFC-Free environmental refrigerant.
  • High density insulation foam layer with better heat preservation effect.











Specification



Parameter Model MDF-40V358
Specificaitons Shelf/drawer Shelves/12 drawers
Cooling method Direct cooling
Defrost Manual
Refrigerant R290
Power consumption(kWh/24h) 5.5
Noise(db) 49
Ambient temperature(℃) 10~32
Temperature range(℃) -20~-40
Cooling system Compressor brand/QTY CUBIGEL/2
Condenser Wire tube
Sensor NTC
Temperature controller Microprocessor
Display Digital display
Power Voltage/frequency(V/Hz) 220/50Hz
Power(W) 310W
Current(A) 3
Material Inside material Color sprayed steel
Outside material Color sprayed steel
Insulation PURF





Size Capacity(L/cu.ft) 358/12.6
NT./GT.(kg) 138/178
Exterior size(W*D*H)(mm) 720×830×1870
Interior size(W*D*H)(mm) 466×636×625
Package size(W*D*H)(mm) 780×920×1990
CBM 1.43
20GP/40GP/40HQ 18/39/39
Alarm High/low temperature Y
Power failure Y
Sensor error Y
Filter check /
Temperature controller failure Y
Low battery /
Condenser clean /
High ambient temperature Y
Door ajar Y
Power failure backup system(alarm) 8H
Accessories Foot Y
Castor Y
Inside door 12DRAWERS
Test hole QTY/diameter Y
USB port Y
Remote alarm port Optional
Other Certification ISO9001,ISO13485,
ISO14001,CE







Packing and Delivery



Packing Method Carton packing with strong belt or Wooding
20GP/40GP/40HQ 18/39/39 Pieces
Loading Port: Shanghai/ Ningbo or other Main port of China
Shipment Term EXW/FOB/FCA/CNF/CFR/CIF
Payment Term 100% TT Before Delivery



R290 Direct Cooling Double Foaming Door Medical Low Temperature Freezer -40 Degree 6





Compamy Information



Anhui Zhongke Duling Commercial Appliance Co.ltd is a high-tech enterprise which specialized in designing,developing and manufacturing medical Freezers more than 10 years, like ultra-low temperature freezers,deep freezers,blood platelet incubators and customized medical freezers, widely used in laboratory & bio-medical storage equipments, cold room, cold-chain logistics and customized instruments.

Our factory locates in Hefei city, Anhui province, China which is near Shanghai and Ningbo port, Annual output is around 18,000 sets Refrigerators.
