Minus 40 Degree 528L Large Capacity High Quality Cryogenic Medical Freezer For Vaccines

$ 2614.5-2863.5 per set
Minus 40 Degree 528L Large Capacity High Quality Cryogenic Medical Freezer For Vaccines
Features Gallery Product Description Request A Quote
Cooling Method: Direct Cooling
Capacity(L/cu.ft): 528/18.64
Voltage/frequency: 220/50Hz
Power Consumption(kWh/24h): 6.7
Temperature Range(℃): '-20°~-40°C
Temperature Controller: Microprocessor
Refrigerant: R290
Defrost: Manual
Package Size(W*D*H)(mm): 930*970*2000
Sensor: NTC
High Light:

528L medical freezer for vaccines


220V medical freezer for vaccines


528L medical deep freezer

Basic Infomation
Place of Origin: ANHUI CHINA
Brand Name: PROMED
Certification: ISO9001,ISO13485, ISO14001,CE
Model Number: MDF-40V528
Payment & Shipping Terms
Packaging Details: Carton packing with strong belt Package size(W*D*H)(mm) 930*970*2000 / 20GP/40GP/40HQ - 12/ 24/24 pieces
Delivery Time: 10-35 days after receiving the 50% deposit
Payment Terms: T/T, Western Union, L/C, MoneyGram, D/A, D/P
Supply Ability: 700 Pieces per month
Product Description
Product Description


-40°C Medical Freezer Cream Color 528L Large Capacity To Store Vaccine In Good Condition

Main Points

Microprocessor control, adjustable temperature range: -20ºC to -40ºC

LED digital display and accurate to 0.1ºC

Independent inner door to avoid more cooling leaking out, and provide more stable inside temperature performance



Multiple malfunction alarms :high and low temperature , sensor error, power off, temperature controller malfunction, door ajar alarms.

Alarm indications: audible buzzing alarm and visual flashing light alarm

Corrosion proof cabinet interior design

Power failure protect: the device would be attack by the high current when all devices restart simultaneously, the start-delay function would protect device from the damage



Chemically stable, CFC -free, commercially available and environmentally safe refrigerant.

Optimized refrigeration system designed to maximize cooling effect and temperature uniformity

Adjustable temperature range: - 20ºC~-40ºC

LED digital display for clear observation,

Wide voltage tolerance design with applicable voltage range of 187-242V/AC


Ergonomic Design

USB data logging and temperature recorder (optional).

Build-in lock with safety and beauty



Specification Parameter


Parameter Model MDF-40V528
Specificaitons Shelf/drawer Shelves/drawers
Cooling method Direct cooling
Defrost Manual
Refrigerant R290
Power consumption 6.7 (kWh/24h)
Noise(db) 55
Ambient temperature 10~32ºC
Temperature range -20°~-40°C
Cooling system Compressor brand/QTY CUBIGEL/2
Condenser Copper tube
Sensor NTC
Temperature controller Microprocessor
Display Digital display
Power Voltage/frequency 220/50Hz
Power(W) 340W
Current(A) 3.4A
Material Inside material Color sprayed steel
Outside material Color sprayed steel
Insulation PURF
Size Capacity(L/cu.ft) 528/18.64
NT./GT.(kg) 151/184
Exterior size(W*D*H)(mm) 910*845*1875
Interior size(W*D*H)(mm) (651*631.5*635)*2
Package size(W*D*H)(mm) 930*970*2000
CBM 1.80
20GP/40GP/40HQ 12/ 24/24
Alarm Systerm High/low temperature Y
Power failure Y
Sensor error Y
Filter check /
Temperature controller failure Y
Low battery /
Condenser clean /
High ambient temperature Y
Door ajar Y
Power failure backup system(alarm) 8h
Accessories Foot Y
Castor Y
Inside door 9Drawer×2
Test hole QTY/diameter 2/25MM
USB port /
Remote alarm port Y
Other Certification ISO9001,ISO13485,



Packing and Delivery


Packing Method Carton packing with strong belt or Wood packing
Package size(W*D*H)  930*970*2000 mm
20GP/40GP/40HQ: 12/ 24/24 Pieces
Loading Port: Shanghai/ Ningbo or other Main port of China
Payment Term 100% TT Before Delivery

Minus 40 Degree 528L Large Capacity High Quality Cryogenic Medical Freezer For Vaccines 0

Minus 40 Degree 528L Large Capacity High Quality Cryogenic Medical Freezer For Vaccines 1



Compamy Information


Anhui Zhongke Duling Commercial Appliance is a high-tech enterprise which specialized in designing,developing and manufacturing medical Freezers more than 10 years, like ultra-low temperature freezers,deep freezers,blood platelet incubators and customized medical freezers, widely used in laboratory & bio-medical storage equipments, cold room, cold-chain logistics and customized instruments.

Our factory locates in Hefei city, Anhui province, China which is near Shanghai and Ningbo port, Annual output is around 18,000 sets Refrigerators.


Minus 40 Degree 528L Large Capacity High Quality Cryogenic Medical Freezer For Vaccines 2
