358L Capacity Minus 40 Degrees 12 Drawers Deep Biomedical Vaccine Freezer With Corrosion Proof Cabinet

1
MOQ
$ 2142-2346 per set
Price
358L Capacity Minus 40 Degrees 12 Drawers Deep Biomedical Vaccine Freezer With Corrosion Proof Cabinet
Features Gallery Product Description Request A Quote
Features
Specifications
Cooling Method: Direct Cooling
Refrigerant: R290
Defrost: Manual
Capacity(L/cu.ft): 358/9.81
NT./GT.(kg): 138/178
Power(W): 310W
Condenser: Wire Tube
Package Size(W*D*H)(mm): 780×920×1990
High Light:

Microprocessor Control Standing Deep Freezer

,

Standing Deep Freezer 12 Drawers

,

Corrosion proof cabinet Standing Deep Freezer

Basic Infomation
Place of Origin: ANHUI CHINA
Brand Name: PROMED
Certification: ISO9001;13485;14001;CE;FDA LIST
Model Number: MDF-40V358
Payment & Shipping Terms
Packaging Details: Carton packing with strong belt Package size(W*D*H) 780×920×1990mm / 20GP/40GP/40HQ - 18/39/39 pieces
Delivery Time: 7-25 days after reveing 50% deposit
Payment Terms: T/T, Western Union, L/C, MoneyGram, D/A, D/P
Supply Ability: 700 Pieces per month
Product Description



358L 12 Drawers Standing Deep Freezer With Dual Freezer Systerm

Product Description



Key Points

  1. Microprocessor control, adjustable temperature range: -10CºC to -25ºC
  2. LED digital display and increment at 0.1ºC
  3. Independent inner door to avoid more cooling leaking out, and provide more stable inside temperature performance
  4. High density CFC-Free urethane foam insulation.



Safety

  1. Multiple malfunction alarms :high and low temperature , sensor error, power off, temperature controller malfunction, door ajar alarms.
  2. Alarm indications: audible buzzing alarm and visual flashing light alarm
  3. Corrosion proof cabinet interior design
  4. Power failure protect: the device would be attack by the high current when all devices restart simultaneously, the start-delay function would protect device from the damage

Reliability

  1. Optimized refrigeration system designed to maximize cooling effect and temperature uniformity
  2. LED digital display for clear observation,
  3. Wide voltage tolerance design with applicable voltage range of 187-242V/AC

Perfect Design

  1. USB data logging and temperature recorder (optional).
  2. Build-in lock with safety and beauty
  3. Lockable caster design for customer to move as needed




Low Temperature Direct Cooling Systerm To Store Medicine Standing Deep Freezer 358L

Two separated cabinet with two compressor to control each storage room,it's safe to storage supplies.



Product Parameters
MDF-40V358
Details Shelf/drawer Shelves/12 drawers
Cooling method Direct cooling
Defrost Manual
Refrigerant R290
Energy consumption(kWh/24h) 5.5
Noise(db) 49
Ambient temperature(ºC) 10~32ºC
Temperature range(ºC) -20~-40ºC
Cooling system Compressor brand/QTY CUBIGEL/2
Condenser Wire tube
Sensor NTC
Temperature controller Microprocessor
Display Digital display
Power Systerm Voltage/frequency(V/Hz) 220/50Hz
Power(W) 310W
Current(A) 3
Material Inside material Color sprayed steel
Outside material Color sprayed steel
Insulation PURF



Dimension Capacity(L/cu.ft) 358/12.6
NT./GT.(kg) 138/178
Exterior size(W*D*H)(mm) 720×830×1870
Interior size(W*D*H)(mm) 466×636×625
Package size(W*D*H)(mm) 780×920×1990
CBM 1.43
20GP/40GP/40HQ 18/39/39
Alarm Systerm High/low temperature Y
Power failure Y
Sensor error Y
Filter check /
Temperature controller failure Y
Low battery /
Condenser clean /
High ambient temperature Y
Door ajar Y
Power failure backup system(alarm) 8H
Accessories Foot Y
Castor Y
Inside door 12DRAWERS
Test hole QTY/diameter Y
USB port Y
Remote alarm port Optional


Packaging & Shipping
Packing Method Carton packing with strong belt
20GP/40GP/40HQ 12/24/24 Pieces
Loading Port: Shanghai/ Ningbo or other Main port of Guangzhou
Shipment Term EXW/FOB/FCA/CNF/CFR/CIF
Payment Term 100% TT Before Delivery



358L Capacity Minus 40 Degrees 12 Drawers Deep Biomedical Vaccine Freezer With Corrosion Proof Cabinet 0







Certifications



Company Profile

Anhui Zhongke Duling Commercial Appliance Co.ltd is a high-tech enterprise which specialized in designing,developing and manufacturing medical Freezers more than 10 years, like ultra-low temperature freezers,deep freezers,blood platelet incubators and customized medical freezers, widely used in laboratory & bio-medical storage equipments, cold room, cold-chain logistics and customized instruments.
Our factory locates in Hefei city, Anhui province, China which is near Shanghai and Ningbo port, Annual output is around 18,000 sets Medical Refrigerators.
