108L Vertical Cryogenic Blood Bank Refrigerator Real Forced Air Cooling 4 Degrees For Hospital

4 Degrees Blood Storage Stainless Steel 108L Vertical Blood Bank Refrigerator For Hospital

4ºC Blood Bank Refrigerator

Promed blood bank refrigerator are specially designed to store blood bags and blood-derived products.


HOT TIPS

• Large storage capacity 66*450ml blood bags
• Individual Arcylic inner doors
• blood bags Reliable control system 4±1°C
• Forced-air cooling system, frost-free
• Build-in back-up battery: 72 hours power failure alarm
• 5 visual and audible alarms

Features

• Accurate microprocessor controller to ensure consistent cabinet temperature 4±1°C
• Specially designed forced-air cooling system to ensure frost-free cabinet and good temperature uniformity
• Three layer toughened glass door with heater to avoid condensation
• 304 stainless steel inner chamber for friendly using and easy cleaning

SAFETY GUARANTEE

• Safety door lock and controller setting password to prevent unauthorized access
• Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 72 hours without AC power
• Inner doors and auto on/off cooling fan to prevent cold air from leaking out when the door is opening
• Visual and audible alarm system: High/low temperature, power failure, sensor error, door ajar, low battery.
• Power failure protection: turn on delay of the cooling system after power failure
• Temperature printer: print current inside temperature automatically per 10 minutes

Humanized design

• 4 casters with stopper for easy moving and fixation
• 4 adjustable shelves and 12 blood baskets for easy using
• Special designed service-free drainage system ensure no water in the cabinet
• Standard 25mm test hole for easy connecting to temperature monitoring systems
• Automatic on/off LED light with manual switch on control panel



REFRIGERATION SYSTEM

• Imported brand compressor work with CFC-Free environmental refrigerant.
• High density insulation foam layer with better heat preservation effect.

	Model	MBC-4V108
Specificaitons	Shelf/drawer	Shelves/2
	Cooling	Forced -air Cooling
	Defrost	Auto
	Refrigerant	R134a
	Power consumption(kWh/24h)	1.95
	Noise(db)	49.6dB(A)
	Ambient temperature(ºC)	10~32ºC
	Temperature range(ºC)	4±1ºC
Cooling system	Compressor brand/QTY	EMBRACO/1
	Sensor	NTC
	Temperature controller	Microprocessor
	Display	Digital display
Power	Voltage/frequency(V/Hz)	220/50Hz
	Power(W)	175W
	Current(A)	1A
Material	Inside material	Stainless steel
	Outside material	Color sprayed steel
	Insulation	PURF
Size	Capacity(L/cu.ft)	108/3.81
	Bloodbags(450ml)	66
	NT./GT.(kg)	74/95
	Exterior size(W*D*H)(mm)	540*630*1030
	Interior size(W*D*H)(mm)	432*462*478
	Package size(W*D*H)(mm)	700*585*1200
	CBM	0.49
	20GP/40GP/40HQ	32/68/68
Alarm	High/low temperature	Y
	Power off	Y
	Temperature controller malfunction	Y
	Backup battery malfunction	Y
	Ambient temperature	10~32ºC
	Power failure backup system(alarm)	72h
Accessories	Caster	Y
	Outer door/Type	1/Heating & Foam glass door
	Inner door	2
	Test hole	1/25MM
	Thermal Printer	Y
	Light	LED
	Temperature recorder	Optional
Other	Qualifications	ISO9001,ISO13485,ISO14001,CE

Anhui Zhongke Duling Commercial Appliance Co.Ltd is a direct sourcing manufacturer with core technology.

Anhui Zhongke Duling Commercial Appliance Co.Ltd is a high-tech enterprise which specialized in designing, manufacturing and marketing of laboratory & bio-medical storage equipments, cold room, cold-chain logistics and customized instruments.

We operate with 2 brands
Mether with Safety, Profession, Environmental protection
Promed with Value, Stability, Energy saving

We pursue the concept of "For a healthy world, For a healthy future" with the strong technical support from R&D team. We produce environmentally friendly products for high-end brand technical areas like research institutes, hospitals, laboratories, commercial retails with the dedication to build a green bridge for health of the humanity and the world.
