Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory

1
MOQ
$ 5071.5-5554.5 per set
Price
Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory
Features Gallery Product Description Request A Quote
Features
Specifications
Refrigerant: HC
Power Consumption(kWh/24h): 14.95
Noise(db): 53
Ambient Temperature(℃): 10~32℃
Temperature Range(℃): -40~-86℃
Inside Material: Stainless Steel
Outside Material: Color Sprayed Steel
Capacity(L/cu.ft): 588/20.76
NT./GT.(kg): 307/368
Samples(2ml): 40000
High Light:

Cascade System ULT Freezer

,

Color Sprayed Steel Low Temp Freezer

,

Energy Save Low Temp Freezer

Basic Infomation
Place of Origin: China
Brand Name: METHER
Certification: CE
Model Number: MDF-86V588
Payment & Shipping Terms
Packaging Details: Package size(W*D*H)(mm):975*1140*2200
Delivery Time: 35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000unit/month
Product Description

Cascade System Ultra Low Temperature Freezer -86 Degree China Manufacturer For Hospital And Laboratory

-86 degree Ultra-low temperature freezer Environmentally Friendly energy save and reduce cost


-86ºC ULT freezer is specially designed and manufactured for long term storage of various biological products, including viruses, germs, erythrocytes, leucocyte and cutis. Applications can be found in blood banks, hospitals, edipemic prevention service, and research institutes, laboratories in electronic and chemical plants, biological engineering institutes and marine fishery companies.



1. Description

The Cascade System's microprocessor control system with 3 separate interior doors that can be opened independently. Minimize frost accumulation in the room.The unique door seal design minimizes the temperature loss when the door is opened. The stainless steel internal handle ensures that the door can be easily opened even in the case of frost. High quality door gasket 5 gasket, 4 sealing ring for door, 1 inner door seal to provide maximum protection against heat intrusion. The sample port on the back makes temperature monitoring convenient.







2. Feature

1. Double-machine cascade refrigeration system using fluorine-free environmentally friendly alkane refrigerant, energy saving 50%
2. VIPIIPLUS second generation vacuum insulation board technology, the refrigerator has good insulation performance, designed for entering the elevator
3. Product structure optimized for biological sample library, can provide storage space of up to 40,000 samples
4. Each component that may generate noise is equipped with special material shock absorbing material, and high-density fire-resistant sound-absorbing cotton is installed around the unit.
5. Microcomputer control, the temperature inside the box is adjustable from -60 to -86 °C, over temperature alarm, power failure memory, and the adjustment accuracy is 0.1 °C;
6. Optimized dual-machine cascade refrigeration system for up to 35% energy savings
7. Microcomputer control, the temperature inside the box is adjustable from -40 to -86 °C, over temperature alarm, power failure memory, adjustment accuracy is 0.1 °C;
8.-86 series product internal and external temperature difference up to 110 ° C, special polyurethane foam insulation layer to avoid cracking and deformation, 150mm insulation material thickness to ensure internal temperature stability
9. Two-machine cascade refrigeration system, carbon dioxide refrigerant energy saving 50%
10. When power is restored, the simultaneous start of all equipment will cause a large impact on the power grid, which may cause the circuit breaker to trip; the specially designed equipment delay start function for this case may make the equipment




Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 0

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 1

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 2

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 3

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 4

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 5

Cascade Cooling System Cryogenic Ultra Low Temperature Freezer For Hospital Laboratory 6
